B&W Turnoverball Gooseneck Hitch Kit

Was: $768.00
Free Shipping
Ships by Monday
Part #: GNRK1116
Our Guarantee
  • Ball size: 2-5/16"
  • Removable ball - Stores upside down in the hitch
  • Complete bed access when not in use
  • Gross towing weight: 30,000 lbs
  • 7500 lbs TW
  • Wheel well release
  • Spring-loaded safety-chain hookups are built in
  • 5/8" Thick, spring-loaded, steel locking pin on end of handle goes all the way through ball to secure it in place
  • Simple installation with included custom mounting kit
  • Below the bed installation
  • No welding required
  • Truck bed does not have to be removed
  • 4" Diameter hole must be cut into bed
  • Complete Kit: GNRM1117 Mount Kit & GNRC816 Center Section

Turnoverball Install Tips

Professional hitch installer Chris Long offers up a selection of tips and tricks he's learned over the years for installing the B&W Turnoverball gooseneck hitch.

Turnoverball Maintenance

General points of keeping your Turnoverball operating smoothly.

Turnoverball: Still the Best Gooseneck Hitch

The history of the Turnoverball Gooseneck Hitch as told by co-creator, Joe Works

From: on May 3, 2021
Heavy duty and easy to install.
Great customer service, heavy duty hitch that was easy to install
Was this review helpful?
From: on March 25, 2021
Easiest to install
Was this review helpful?
Write a review

No questions have been asked about this product yet. Have a question? Ask it below!

With the B&W Turnoverball underbed gooseneck trailer hitch you get the best of both worlds. When you go to tow, the Turnoverball creates a sturdy, dependable connection with your gooseneck trailer. And when you're done towing, you can stow the ball upside down in the hitch to get full bed access and a clean appearance.

The durable steel hitch ball included with the Turnoverball system secures in the hitch with a sturdy, 5/8" thick steel pin that is incorporated into the end of the operating handle. To lock the ball in place, drop it into the hitch hole in the bed of your truck. Then rotate the handle in your driver's-side wheel well counterclockwise until the latch engages. When the latch is engaged, the spring-loaded pin on the end of the handle will be inserted all the way through the base of the hitch ball, forming a strong, solid connection and ensuring absolute security when you're towing.

This hitch is custom designed for your vehicle. The included mounting brackets bolt to existing holes in your truck's frame. While some modification is required - you will need to cut a 4" diameter hole in your bed for the hitch ball and drill holes for the built-in safety chain loops - there is no need to weld onto or to drill into your frame.

Once you have the hitch brackets and body installed, set up the operating handle. This handle is designed to be accessed from the rear driver's-side wheel well. On the end of the handle is the heavy-duty steel pin that secures the hitch ball.

Brand B&W Hitches
Length 8 inch(es)
Width 25 inch(es)
Height 5 inch(es)
Weight 70 lb(s)
UPC 00843233004502

  • 2022 Ford F-250 Super Duty
  • 2022 Ford F-350 Super Duty
  • 2022 Ford F-450 Super Duty
  • 2021 Ford F-250 Super Duty
  • 2021 Ford F-350 Super Duty
  • 2020 Ford F-250 Super Duty
  • 2020 Ford F-350 Super Duty
  • 2019 Ford F-250 Super Duty
  • 2019 Ford F-350 Super Duty
  • 2018 Ford F-250 Super Duty
  • 2018 Ford F-350 Super Duty
  • 2017 Ford F-250 Super Duty
  • 2017 Ford F-350 Super Duty
